Design, Draft & Cost Planning

Knowledgeable Draftsman in Townsville

Aerial View of a Construction Area — Norfab In Bohle, QLD

Design, Draft & Cost Planning Services

Leveraging our proficiency in design, drafting and certification within our industry yields significant advantages, leading to streamlined timelines and enhanced cost-efficiency. At Norfab, we pride ourselves on delivering a comprehensive range of specialised services tailored to your needs, including:

CAD & design
Shop drawings
Remote travel
Laser Scanner
Engineer sign-off

In essence, our multidimensional approach empowers us to significantly reduce project timelines and costs while maintaining the highest standards of precision and quality. We’re dedicated to providing a suite of services that embody excellence at every step of your mining, commercial or residential construction project’s journey.

Contact our draftsman to book. Based in Garbutt, we assist clients throughout Townsville, Mount Isa, Mackay, Hughenden, Julia Creek and Cairns.

Get in Touch

Leveraging CAD Technology

CAD is essential for any successful steel fabrication project. By leveraging this technology, we can ensure design accuracy and cost savings for our customers. CAD software allows us to create detailed 3D models, which are then used to manufacture highly precise parts with complex geometries. We've optimised the design process, reducing material waste and improving product quality.

By creating a 3D model of the steel product upfront, our team can easily identify problems that could arise during production. This means we can prepare our designs for installation and avoid delays. Reach out to learn more about our processes.
